Digital Temperature Controller D1S-VR-220 AC100-24V, Control Range -50~1300 ℃ (K Sensor) Indication and Control, Alarm 1: Relay Accuracy 0.1 ℃, ± 0.2% FS, Output: Voltage 12V for SSR

Features: DIN(48X48mm) Digital counter 0.01s-99h99m time range with twin time set value individual, Output for A,B Period One shot or cycle time mode, up or down mode available MCU for digital countrol, High accuracy and reliability NPN and PNP input switchable 0.39" height LED,Prevent dazzle,Highly visible display Tact switch for up or down set value,easily operate Key lock function, Prevent mistake operation Switching power supply and low consumptionMechanical≥10,000,000 operations Electrical≥10,000,000 operations Accuracy: 1.1% +-0.05s Countrol Signals: >=5ms(Reset, Gate) Control/Input Type: Contact/No-voltage input(NPN)/Voltage input(PNP) External Power: DC12V/50mA(Max.) for sensor use only. Reset Method: Power on/External/Manual Cutout size: 45x45mm Mounting Method: Flush mounting and screw terminals Weight: Approx. 130g Environmental

• DIN (48X48mm) temperature controller, support multi-sensor input (K, S, Wre, T, E, J, B, N, CU50, PT100)
• Wide control range -50～1300℃(K sensor),Indication and control accuracy 0.1℃, ±0.2%FS
• PID and ON / OFF control mode, built-in digital filter to reduce interference, built-in digital filter to reduce interference
• Auto turning technology, parameter lock,Output: Voltage 12V for SSR, Alarm 1: Relay
